Max Feeding Width:as per drawings
Product Max Effective Width: as per drawings
Thickness of Panel: 0.2-4.0 mm
Material Type: GI sheet coil or cold rolled coil or Aluminium etc.
Diameter of Main Shaft: 95 mm; Rollers Station: 15 Rows
Roller Material: C45 steel,Heat Treatment
Surface of Roller: Chrome plating, Heat Treatment
Driving Mode: By Chain and Gear Box
Main Motor Power: 5.5 Kw
Machine Body: Electrostatic Spraying Treatment[1]
The machine base is assembled and welded by high quality steel
Forming Speed: Min. 0-15 m/min
Electrical System: PLC and HMI touch Screen (Taiwan Delta)[2] : It can be modified as per customers requirements, such as Siemens, and the operation system language can be specified, such as English, French, Russian and so on
.
